Trio

Overview

The Trio is Peco InspX’s high performance rigid package X-ray inspection system, with impressive performance in glass-in-glass identification. The Trio offers very high speed (> 1,000 containers per minute) non-contact container inspection.

The Trio leverages three X-ray beams powered from a single X-ray tube to provide 3 individual “looks” at each container, which allows optimal detection of asymmetric pieces of foreign material such as glass shards.

Customers are encouraged to consult with a Peco InspX sales specialist to determine which machine is best suited for their glass application.

Request DetailsFood and Beverage Guide

Features

Modular Design

All subsystems have been designed with the maximum system availability, redundancy, and fault tolerance in mind

Fill Level Measurement

High precision fill-level and headspace monitoring

Real-Time Remote Support

Integrated wireless connectivity allows for secure remote support 24/7 globally. Peco InspX can resolve over 95% of customer issues with our powerful remote diagnostics software

Robust IT Security

Fully integrated end-to-end IT security offerings ensure your networks aren’t vulnerable and are defended from any outside threats. Optional IoT module allows for seamless SCADA integration

Advanced X-ray Tube/Detector Design

High contrast X-ray tube with independent power supply allows for lowest cost of ownership. Detector hardened against wear to maximize the component lifetime

High Reliability Non-Contact Inspection

Mounts over the top of the customer’s existing conveyor, eliminating conveyor transfers into the machine for inspection. This design minimizes risk against conveyor jams over transfer points

3 Beams Powered by a Single X-ray Tube

The Trio offers the power of 3 X-ray beams with the simplicity of a single X-ray tube. This design offers maximized performance with minimum cost of ownership

Small Line Footprint

The Trio is the smallest footprint dedicated glass X-ray inspection system available on the market today. The Trio requires less than 9 ft (3 m) of linear line space

Typical Applications

Glass Food Containers
Glass Beverage Containers
Empty Glass Containers

What Makes Peco Inspx X-ray Systems Different?

Continuous research and development drives engineering excellence for all Peco InspX inspection systems. If you have an application that may benefit from Peco InspX’s inspection expertise, please contact us to learn more about how we can be of assistance. All inspection systems are delivered with four key features:

High Speed Operations
Manufacturers can easily operate at speeds over 1000 containers per minute - Peco InspX offers inspection, checkweighing and fill monitoring capable to match such performance.
Service
Peco InspX strives to deliver the very best service in the industry and the quality of our service is well recognized across our global customer base.
Software
Our inspection and detection software is custom designed constantly enhanced for technical excellence at our R&D facility in Silicon Valley.
Made in America
All systems are manufactured in our newly expanded facility in Modesto, California.

Tech Specs

Technical Information

Architecture
Side view X-ray system
Conveyor
No internal conveyor. Mounts over customer’s existing conveyor. No transfer points or product contact
X-ray Tube Configuration
High contrast X-ray tube – triple beam
Aperture Size
Max Width: 9 in (229 mm) Max Height: 12 in (300 mm)
Environment
Standard: IP 66/NEMA 4X Optional: IP 69K, Passivation
Line Speed
Up to 650 ft/min (198m/min)
Input Voltage
Available in 120 or 240 VAC options
Air Supply
80 psi @ 5 cfm (for ejection only)
Ambient Temperature
33°F – 113°F (1°C – 45°C)
Diode Size
Configurable to 0.8 mm, 0.4 mm and 0.2 mm
Container Ejection
Full range of high-speed ejection and diversion options available
Dimensions (LxDxH)
104 x 43 x 82 in (2,640 x 1,092 x 2,083 mm)
Safety Rating
Redundant – Category 4, Performance Level E
Computer
Solid State Industrial PC with Windows 10 and integrated AV
Connectivity
Integrated WiFi, Ethernet or Cellular Connection
Supported SCADA Systems
Ignition, Wonderware, FactoryTalk, Kepware and other OPC-UA compliant systems
Supported Cloud Platforms
Azure IoT Hub, AWS and Google Cloud via MQTT
Operator Interface
20" wide touchscreen
Construction
Standard: 304 Stainless Steel Optional: 316L/Passivated

Technical Information

Options

Industrial IoT Capabilities

Peco InspX offers industry leading plant connectivity and remote control including:

  • SCADA integration via OPC-UA protocol into Ignition, Wonderware, FactoryTalk, Kepware and all other popular integrated software platforms
  • Native support for Azure, AWS, and Google Cloud via MQTT
  • Real time system and performance monitoring of each machine
  • Insight into operational performance bottlenecks
  • Automatic archiving and classification of reject images
  • Optional archiving of all inspection images
Reject Management Package

Reject Management Package include secure options:

  • Lockable reject bin to ensure authorized access to rejected packages
  • Sensors to ensure positive confirmation on expected rejects
  • Sensors to alert on “bin full” condition
  • Air pressure sensor to alert for any out-of-range air supply problems
  • Optional software controlled lock for user configurable access
Simultaneous Underfill and Overfill Monitoring

With the addition of a Peco InspX FillTrac, the system can simultaneously measure underfill and overfill levels

Cocked/Missing Cap Detection

The cocked/missing cap sensor for plastic closures is an inexpensive way to ensure that containers are properly capped

Track and Trace Capabilities

In collaboration with industry-leading industrial package printers, Peco InspX offers an end-to-end package tracing system that prints on the inspected container the status (good or bad) of every package to ensure packages are auditable to their inspection results and X-ray image

Full Range of Ejection Options

Peco InspX designs and manufactures a wide range of high performance ejectors and diverters to include single solonoid, multiple solonoid, swing arm, lift gate, drop gate, air blast, flexible rail, guided path, and heavy duty options

Remote Operator Console

The remote operator console provides complete system monitoring and control up to 6 meters from the system inspection assembly

RFID Access Control

Support automatic system authentication using customer ID badges. Supports a wide range of standard access protocol frequencies

Sanitary Design

Can be equipped with an IP69K enclosure for high pressure wash down environments

Missing Foil Detection

The missing foil sensor verifies the presence of foil seals under caps
